Holzmann EHH 110 planer, mains operation
The HOLZMANN EHH110_230V is the ideal device for fast planing work that does not require a stationary planing machine. Handy and compact, it is nevertheless very versatile and can be used both as a hand planer and as a dressing planer. With the V-groove guide on the receiving table, chamfers can be made, with the depth stop included, even steps/ rebate cuts are possible.
Features:
- 110 mm planing width
- V-groove for easy chamfering
- Receiving table: 104 x 100 mm; Dispensing table: 214 x 100 mm
- Maximum fold depth: 14 mm
- High planing shaft speed enables perfect finish
- Planing depth adjustment via hand wheel 0-3 mm
- Extensive accessories
Scope of delivery:
- Parallel stop
- Rebate depth stop
- 2x planer blades (110 x 5.7 x 1.2 mm),
- Dust bag
- Extraction reduction diameter 35-32 mm
- Frame and plane shaft cover
Technical data:
- Dressing maximum chip removal: 3 mm (110 mm)
- Motor power S1 in W: 1200
- Voltage: 230V / 50Hz
- Protection class: II
- Suction connection diameter: 35 mm
- Planing shaft speed: 16000 rev/min
- Number of knives: 2
- Sound power level: 96 dB(A)
- Sound pressure level: 85 dB(A)
- Vibration handle: 5.71 m/s2
- Net weight: 4.40 kg
- Color: red / black
