LC-Power LC6850B-SI V3.1, PC Power Supply, PCIe 5.1, 850 W
The LC6850-SI V3.1 is an 80 PLUS BRONZE-certified ATX power supply that provides good performance and system stability. The Integrator series power supply offers a power output of 850 watts and is a reliable power solution for a variety of applications. Equipped with a quiet 135 mm fan, it operates efficiently and ensures powerful cooling. It is ideal for all mid-range systems.
It features a 20+4-pin mainboard connector that is compatible with most motherboards, as well as a 550 mm 4+4-pin mainboard 12V connector, a 750 mm 4+4-pin mainboard 12V connector, four SATA and two PATA, providing stable power for high-performance CPUs, hard drives, and optical drives. For graphics cards, it has two PCI-Express 6+2-pin connectors and a powerful PCI-Express 5.1 12V 2x6 12+4-pin connector, enabling direct and reliable power for multiple GPUs.
Features:
- ATX Form Factor, V 3.1
- Power: 850 W
- Fan: 135 mm
- Black flat cables
- 80 PLUS Bronze certified
- Efficiency up to 85%
- Six safety circuits
- DC-to-DC technology
- Powerful +12 V rail: 70.8 A
- Connectors:
- 1x Mainboard 20+4-pin, Cable Length: 550 mm
- 2x Mainboard 4+4-pin 12V, 8-pin EPS, Cable Length: 1x 550 / 1x 700 mm
- 1x PCIe 5.1 / 12V, 12+4-pin, Cable Length: 1x 600 mm
- 2x PCIe 6+2-pin, Cable Length: 1x 550 / 1x 700 mm
- 4x SATA, Cable Length: 2x 450 / 2x 600 mm
- 2x PATA, Cable Length: 2x 750 mm
- PFC: Active
- Input AC: 100 – 240 V
- Output DC: 3.3 / 5 / 12 V (20 / 20 / 70.8 A)
- Safety Circuits: OCP (Overcurrent Protection), OPP (Overpower Protection), OVP (Overvoltage Protection), SCP (Short Circuit Protection), SIP (Surge Protection), UVP (Undervoltage Protection)
- Material: Metal, Plastic
- Dimensions: 86 x 150 x 150 mm
- Weight: approx. 1.88 kg
- Color: Black
